Bristan Single Soft Touch Timed Flow Tap Z2 BIB C

Single Soft Touch Timed Flow Tap Z2 BIB C

Single Soft Touch Timed Flow Tap Chrome - Timed shut off to meet BS EN 816. Soft touch easy to use mechanism. Supplied with both hot and cold indices. Supplied with 5 L/min flow regulator. Operates at a minimum pressure of 0.5 bar.

Product Specifications

• Chrome finish
• Product Type: Utility
• Construction: Body is of brass construction and is designed to conform to BS EN 200
• Valve Type: Self closing valve
• Supply: Suitable for all plumbing systems
• Inlet Connections: 1/2" BSP
• Working Pressures: Min 0.5bar, Max 5.0bar

Additional Information

• Supplied with flow limiter to reduce flow to a max of 6 l/min
• Approximately 9 second shut off
• Supplied with cold and hot indices for either installation
• Chrome plated to BS EN 248
• Bristan Single Soft Touch Timed Flow Tap Z2 BIB C Datasheet (PDF)
• Bristan Single Soft Touch Timed Flow Tap Z2 BIB C Fitting Instructions (PDF)


Bristan Single Soft Touch Timed Flow Tap Z2 BIB C - As a result of thorough design brings an excellent, reliable component which couples reliable build with an exceptional finish and thanks to HomeSupply you can own the Bristan Single Soft Touch Timed Flow Tap Z2 BIB C at a competitive price and benefit from our respected customer service.
